DSC OPERATION
■
Setting the distress information
The nature of the distress call should be included in the dis-
tress call.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Distress Setting,”
push [ENT].
e Rotate [CHANNEL] to select the nature of the distress,
push [ENT].
•‘Undesignated,’ ‘Explosion,’ ‘Flooding,’ ‘Collision,’ ‘Grounding,’
‘Capsizing,’ ‘Sinking,’ ‘Adrift (Disable adrift),’ ‘Abandoning (Aban-
doning ship),’ ‘Piracy (Piracy attack)’ and ‘MOB (Man overboard)’
are available.
r The position information appears. Set the current position,
then push [ENT].
• Edit the digit of your position data directly with the keypad.
•Push [6• ] to edit N; North latitude or [7• ] to edit
S; South latitude.
•Push [3• ] to edit E; East longitude or [9• ] to edit
W; West longitude.
• Rotate [CHANNEL] to move the cursor backward or forward.
• Push [CE] to clear the position data.
WXYDEF
PRSMNO
Select Nature
˘Undesignated
˘Flooding
--DSC Menu--
˘
˘Collision
˘Grounding
˘Abandoning
˘Capsizing
˘Sinking
˘Adrift
<CLR˘Exit / ENT˘OK>
˘Piracy
˘MOB
˘-----
˘Explosion
Select item
˘Exit
˘Position Request
˘Received Calls
--DSC Menu--
˘Set up
˘Distress Setting
˘Polling Request
