Automatic fog horn frequency
The audio frequency of the automatic fog horn can be ad-
justed to suit your preference. While this item is selected,
pushing [PTT] outputs the fog horn—experiment with the fre-
quencies available until you find one you like.
•Available frequency range is 200 Hz to 850Hz in 50 Hz step.
DD
Scrambler type
(Appears when a scrambler unit is installed)
When an optional scrambler unit is installed, the scrambler
type can be selected in set mode depending on dealer set-
ting.
Although the UT-98 is not listed on the option list, M602
would take UT-98 as well as UT-112.
DD
Scrambler code
(Appears when a scrambler unit is installed)
When an optional scrambler unit is installed, the scrambler
code can be set depending on dealer setting.
When the UT-112 is installed, 32 codes (1 to 32) can be se-
lected.
Scrambler Code
˘5
˘300
--Set Mode--
˘100
˘250
˘4
˘<ENT˘OK>
(Default: 1)
Scrambler Type
˘UT-98
˘300
--Set Mode--
˘200
˘250
˘UT-112
˘<ENT˘OK>
(Default: UT-112)
Foghorn Frequency
˘400
˘300
--Set Mode--
˘200
˘250
˘350
˘<ENT˘OK>
(Default: 400)
