DSC OPERATION
DD
Transmitting Position reply call
Transmit a position reply call when a position request call is
received.
q When a position request call is received, the following in-
dication is displayed.
w Push [ENT] to reply to the position request call; push [CLR]
to ignore the position request call.
DD
Transmitting Polling request call
Transmit a polling request call when you want to know a spe-
cific ship is in the communication area, etc.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Polling Request,”
push [ENT].
e Rotate [CHANNEL] to select the desired pre-pro-
grammed individual address or “Manual Input,”
push [ENT].
• The ID code for the individual call can be set in advance. (p. 31)
• When “Manual Input” is selected, set the 9-digit ID code for
the individual you wish to call with the keypad.
Select Address
<CLR˘Exit / ENT˘OK>
˘Manual Input
˘Margaret
--DSC Menu--
˘Ricky
˘John
Select item
˘Received Calls
˘Individual Call
˘All Ships Call
--DSC Menu--
˘Polling Request
˘Position Request
˘Group Call
BUSY-25W---INT---CALL
LOCAL--DUP
SCRAM--TAG
ReceivedCAN
POS REQ
<Chuck3
<CLR˘Exit>
<ENT˘Reply>COMMERCIAL
