39
6
DSC OPERATION
DD
Other messages
q Rotate [CHANNEL] to select “Other,” push [ENT].
w Rotate [CHANNEL] to scroll to the desired message, push
[ENT].
•When some messages are blinking, the messages have not
been read yet.
e Rotate [CHANNEL] to scroll the message.
• The stored message has various information and depending on
the type of distress call.
r Push [CLR] to exit the condition or push [CE] to clear the
displayed message and returns to DSC menu.
Group Call
<Chuck3
>OSAKA-1
--DSC Menu--
F3E simplex
Routine
<CLR˘Exit / CE˘Del>
Group Call
--DSC Menu--
CH10
>OSAKA-1
F3E simplex
Routine
<CLR˘Exit / CE˘Del>
--DSC Menu--
<CLR˘Exit / ENT˘OK>
Select Message
˘Position Request
˘Individual Call
˘Group Call
˘Individual Call
--DSC Menu--
<CLR˘Exit / ENT˘OK>
Select Message
˘Distress
˘Other
