33
6
DSC OPERATION
DD
Programming Group ID
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Set up,” push [ENT].
e Rotate [CHANNEL] to select “Add: Group ID,” push
[ENT].
r Set the group ID and ID name.
• Edit the 8-digits of the group ID directly with the keypad.
• Push the appopriate keypad several times to edit the character.
• Rotate [CHANNEL] to move the cursor backward or forward.
• Push [CE] to clear the ID and name.
• Push [CLR] to cancel and exit the condition to DSC set up menu.
t Push [ENT] to program and exit the condition to DSC set
up menu.
DD
Deleting group ID
q Push [MENU] to select the DSC menu.
w Rotate [CHANNEL] to select “Set up,” push [ENT].
e
Rotate [CHANNEL] to select “DEL: Group ID,” push [ENT].
• When no group ID is programmed, the transceiver exits the con-
dition automatically.
r
Rotate [CHANNEL] to select the desired ID name for deleting.
t Push [ENT] to delete the group ID and exit the condition
DSC set up menu.
Set up
˘MMSI Check
˘Add:INDV ID
˘DEL:INDV ID
--DSC Menu--
˘Offset time
˘DEL:Group ID
˘Add:Group ID
Add:Individual ID
Input 8 digits
Input name
--DSC Menu--
˘
__________________
˘0
ä______________
Set up
˘MMSI Check
˘Add:INDV ID
˘DEL:INDV ID
--DSC Menu--
˘Offset time
˘DEL:Group ID
˘Add:Group ID
Select item
˘Exit
˘Position Request
˘Received Calls
--DSC Menu--
˘Set up
˘Distress Setting
˘Polling Request
