Icom IC-M602 [59/78] I dimensions
![Icom IC-M602 [59/78] I dimensions](/views2/1074668/page59/bg3b.png)
53
9
CONNECTIONS AND MAINTENANCE
■ Dimensions
220.0 (8
21
⁄32˝)
31.4
(1
1
⁄4˝)
78.0
(3
1
⁄16˝)
110.0 (4
11
⁄32˝)
109.4 (4
29
⁄32˝)
200.0 (7
7
⁄8˝)
Unit: mm (inch)
90.0 (3
17
⁄32˝)
