22
6
DSC OPERATION
■ Transmitting DSC calls
DD
Transmitting Individual call
The individual call function allows you to transmit a DSC sig-
nal to a specific ship only.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Individual Call,”
push [ENT].
e Rotate [CHANNEL] to select the desired pre-programmed
individual address or “Manual Input,” push [ENT].
• The ID code for the individual call can be set in advance. (p. 31)
• When “Manual Input” is selected, set the 9-digit ID code for
the individual you wish to call with the keypad.
r Rotate [CHANNEL] to select a desired intership channel
or “Manual Input,” push [ENT].
• When “Manual Input” is selected, rotate [CHANNEL] to se-
lect the desired channel other than Channel 70.
Select Intership CH
<CLR˘Exit / ENT˘OK>
˘08
˘77
--DSC Menu--
˘
˘06
˘69
Select Address
<CLR˘Exit / ENT˘OK>
˘Manual Input
˘Margaret
--DSC Menu--
˘Ricky
˘John
Select item
˘Received Calls
˘Individual Call
˘All Ships Call
--DSC Menu--
˘Polling Request
˘Position Request
˘Group Call
