![Icom IC-M602 [32/78] Dsc operation](/views2/1074668/page32/bg20.png)
26
6
DSC OPERATION
DD
Transmitting All ships call
Large ships use Channel 70 as their ‘listening channel.’ When
you want to announce a message to these ships, use the ‘all
ships call’ function.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “All Ships Call,” push
[ENT].
e Rotate [CHANNEL] to select the desired category, push
[ENT].
• Output power of ‘Routine’ category is 1 W (low power) only.
r Push [ENT] to transmit the all ships call.
• Channel 70 is selected and the all ships call is transmitted.
t After the all ships call has been transmitted, the following
indication is displayed.
y Push [CLR] to exit the condition.
•Even if [CLR] hasn’t been pushed, the display automatically
changes to channel 16 after 5 sec. inactivity.
All Ships Call
TX Complete
<CLR˘Exit>
--DSC Menu--
All Ships Call Ready
<CLR˘Exit / ENT˘OK>
--DSC Menu--
Select Category
˘Received Calls
˘Routine
˘Urgency
--DSC Menu--
˘Polling Request
˘Position Request
˘Safety
Select item
˘Received Calls
˘Individual Call
˘All Ships Call
--DSC Menu--
˘Polling Request
˘Position Request
˘Group Call
