24
6
DSC OPERATION
r Rotate [CHANNEL] to select an acknowledgement “Able
to Comply” or “Unable to Comply,” push [ENT].
t If you select “Unable to Comply,” select the reason
by rotating [CHANNEL], push [ENT].
• ‘No reason given,’ ‘Congestion,’ ‘Busy,’ ‘Queue indication,’ ‘Sta-
tion Barred,’ ‘No operator,’ ‘Operator Unavailable,’ ‘Equipment
Disable,’ ‘Channel Unable’ and ‘Mode Unable’ are available.
y Push [ENT] to transmit the acknowledgement to the se-
lected station.
u After the individual acknowledgement has been transmit-
ted, the following indication is displayed.
i Then the display changes to the channel specified by the
calling station, automatically.
Individual ACK
TX Complete
--DSC Menu--
Individual ACK Ready
<CLR˘Exit / ENT˘OK>
--DSC Menu--
Select Reason
˘No Reason Given
˘Busy
--DSC Menu--
˘
˘Queue Indication
˘Station Barred
˘Channel Unable
˘No Operator
˘Operator Unavailable
˘Equipment Disable
<CLR˘Exit / ENT˘OK>
˘Mode Unable
˘Equipment Disable
˘Congestion
Select Action
<CLR˘Exit / ENT˘OK>
˘Able to Comply
˘77
--DSC Menu--
˘
˘06
˘Unable to Comply
