37
6
DSC OPERATION
DD
MMSI code check
The programmed 9-digit MMSI (DSC self ID) code can be
checked in DSC set mode.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Set up,” push [ENT].
e Rotate [CHANNEL] to select “MMSI check,” push
[ENT].
r Check the 9-digit MMSI (DSC self ID) code.
t Push [CLR] or [ENT] to exit the condition to DSC set up
menu.
MMSI Check
˘123456789
--DSC Menu--
<CLR˘Exit>
Set up
˘MMSI Check
˘Add:INDV ID
˘DEL:INDV ID
--DSC Menu--
˘Offset time
˘DEL:Group ID
˘Add:Group ID
Select item
˘Exit
˘Position Request
˘Received Calls
--DSC Menu--
˘Set up
˘Distress Setting
˘Polling Request
