18
6
DSC OPERATION
■ MMSI code programming
The 9-digit MMSI (Maritime Mobile Service Identity: DSC self
ID) code can be programmed at power ON.
This code programming can be performed only twice.
q Turn power OFF.
w While pushing [MENU], turn power ON to enter MMSI
code programming condition.
e After the display appears, release [MENU].
r Push [MENU] to enter the DSC menu.
t Rotate [CHANNEL] to select “Set up,” push [ENT].
y
Rotate [CHANNEL] to select “MMSI check,” push [ENT].
u Edit the specific MMSI code directly with the keypad.
• Rotate [CHANNEL] to move the cursor backward or forward.
i Input the 9 digit code, then push [ENT] to set the code.
• Returns to the DSC set up menu.
o Rotate [CHANNEL] to select “Exit,” push [ENT].
• Returns to the DSC menu.
• Repeat again to return to the normal operation condition.
■
Position and time programming
A distress call should include the ship’s position and time. If
no GPS is connected, your position and UTC (Universal Time
Coordinated) time should be input. They are included auto-
matically when a GPS receiver (NMEA0183 ver. 2.0) is con-
nected.
This manual programming is not available when a GPS re-
ceiver (NMEA0183 ver. 2.0) is connected.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Position Input,” push
[ENT].
e Edit the digit of your latitude data directly with the keypad.
•Push [6• ] to edit N; North latitude or [7• ] to edit
S; South latitude.
• Rotate [CHANNEL] to move the cursor backward or forward.
• Push [CE] to clear the position data.
PRSMNO
Input Position
Latitude
Longitude
--DSC Menu--
<CE˘Null Data>
___°__.___W˘˘˘˘˘˘˘˘Null
˘_°__.___N˘˘˘˘˘˘˘˘Null
<CLR˘Exit / ENT˘OK>
MMSI Check
˘
ä________________
--DSC Menu--
<CLR˘Exit / ENT˘OK>
