31
6
DSC OPERATION
t The time information appears. Set the current UTC time,
push [ENT].
• Edit the digit of the current UTC time directly with the keypad.
• Push [CLR] to abandon the setting and exit the condition to se-
lecting the nature menu.
• Rotate [CHANNEL] to move the cursor backward or forward.
• Push [CE] to clear the time.
• The selected nature of the distress is stored for 10 minutes.
y Push [DISTRESS] for 5 sec. to transmit the distress call.
■ DSC individual ID
A total of 100 DSC address IDs can be programmed and
named with up to 10 characters.
DD
Programming Address ID
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Set up,” push [ENT].
e Rotate [CHANNEL] to select “Add: INDV ID,” push
[ENT].
Set up
˘MMSI Check
˘Add:INDV ID
˘DEL:INDV ID
--DSC Menu--
˘Offset time
˘DEL:Group ID
˘Add:Group ID
Select item
˘Exit
˘Position Request
˘Received Calls
--DSC Menu--
˘Set up
˘Distress Setting
˘Polling Request
Input UTC time
˘__:__˘˘˘˘˘˘˘˘˘˘˘˘Null
--DSC Menu--
<CE˘Null Data>
<CLR˘Exit / ENT˘OK>
Input Position
Latitude
Longitude
--DSC Menu--
<CE˘Null Data>
___°__.___W˘˘˘˘˘˘˘˘Null
˘_°__.___N˘˘˘˘˘˘˘˘Null
<CLR˘Exit / ENT˘OK>
