DSC OPERATION
DD
Transmitting Group call
The Group call function allows you to transmit a DSC signal
to a specific group only.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Group Call,” push
[ENT].
e Rotate [CHANNEL] to select the desired pre-programmed
group address or “Manual Input,” push [ENT].
• The ID code for the group call can be set in advance. (p. 33)
• When “Manual Input” is selected, set the 8-digit ID code for
the group you wish to call with keypad.
r Rotate [CHANNEL] to select a desired intership channel
or “Manual Input,” push [ENT].
• When “Manual Input” is selected, rotate [CHANNEL] to se-
lect the desired channel other than Channel 70.
t Push [ENT] to transmit the group call.
• If Channel 70 is busy, the transceiver stands by until the channel
becomes clear.
y After the group call has been transmitted, the following in-
dication is displayed.
u Push [CLR] to exit the condition.
Group Call
TX Complete
<CLR˘Exit>
--DSC Menu--
Group Call ready
<CLR˘Exit / ENT˘OK>
--DSC Menu--
Select Address
<CLR˘Exit / ENT˘OK>
˘Manual Input
˘Osaka
--DSC Menu--
˘
˘Tokyo
˘I-com
Select item
˘Received Calls
˘Individual Call
˘All Ships Call
--DSC Menu--
˘Polling Request
˘Position Request
˘Group Call
