![Icom IC-M602 [52/78] Set mode](/views2/1074668/page52/bg34.png)
46
8
SET MODE
DD
Beep tone
You can select silent operation by turning beep tones OFF, or
you can have confirmation beeps sound at the push of a
switch by turning beep tones ON.
The optional HM-127 has it’s own setting for the beep tone.
DD
Internal speaker
When an external speaker is connected and the transceiver’s
internal speaker is not required, the speaker on the trans-
ceiver and microphone can be deactivated.
DD
LCD contrast
This item adjusts the contrast of the LCD in 8 steps.
The optional HM-127 has it’s own setting for the LCD con-
trast.
DD
Attenuation level
This item sets the receive attenuation level for the attenuator
function from 3 levels.
RF Attenuator
˘Max
˘Min
--Set Mode--
˘1
˘2
˘Mid
˘<ENT˘OK>
(Default: Min)
Contrast
˘5
˘3
--Set Mode--
˘1
˘2
˘4
˘<ENT˘OK>
(Default: 5)
Internal Speaker
˘ON
˘OFF
--Set Mode--
˘Polling Request
˘Position Request
˘OFF
˘<ENT˘OK>
(Default: ON)
Beep
˘ON
˘OFF
--Set Mode--
˘Polling Request
˘Position Request
˘OFF
˘<ENT˘OK>
(Default: ON)
