23
6
DSC OPERATION
t Push [ENT] to transmit the individual call.
• If Channel 70 is busy, the transceiver stands by until the channel
becomes clear.
y Standby on Channel 70 until an acknowledgement is re-
ceived.
u When the acknowledgement is received, the display
changes to the previously selected channel with beeps.
i Push and hold [PTT] to communicate your message to the
responding ship.
DD
Transmitting Individual acknowledgement
Transmit an acknowledgement (‘able to comply’ or ‘unable to
comply’) when an individual call for you is received.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Individual ACK,” push
[ENT].
•“Individual ACK” item appears after an individual call is
received.
e Rotate [CHANNEL] to select the desired individual address
or ID code, push [ENT].
Select Address
<CLR˘Exit / ENT˘OK>
˘Manual Input
˘Margaret
--DSC Menu--
˘Ricky
˘John
Select item
˘Polling Request
˘Individual Call
˘Group Call
--DSC Menu--
˘Position Request
˘All Ships Call
˘Individual ACK
Individual Call
<CLR˘Exit>
TX Complete
Now Waiting for ACK
--DSC Menu--
˘
˘Ricky
˘Icom
Individual Call Ready
<CLR˘Exit / ENT˘OK>
--DSC Menu--
Individual Call
CH70 BUSY
<CLR˘Exit>
--DSC Menu--
Push [ENT] to transmit DSC call. When Ch 70 is busy.
