DSC OPERATION
■ DSC set mode
DD
Offset time
This item sets the offset time from the UTC (Universal Time
Coordinated) time.
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Set up,” push [ENT].
e Rotate [CHANNEL] to select “Offset time,” push
[ENT].
r Set the offset time from the UTC (Universal Time Coordi-
nated) time.
• Edit the digit of offset time directly with the keypad
• Push [0• ] to edit or delete “-”, when the cursor is on the first
digit.
• Rotate [CHANNEL] to move the cursor backward or forward.
• Push [CE] to clear the time data.
•Push [CLR] to cancel and exit the condition to DSC set up menu.
t Push [ENT] to program and to exit the condition to DSC
set up menu.
The local time indication is not available when a GPS re-
ceiver (sentence formatter RMC) is input, the transceiver’s
display indicates UTC time only.
Input Offset Time
