Icom IC-M602 [26/78] I distress call
![Icom IC-M602 [26/78] I distress call](/views2/1074668/page26/bg1a.png)
20
6
DSC OPERATION
■ Distress call
A distress call should be transmitted, if in the opinion of the
Master, the ship or a person is in distress and requires imme-
diate assistance.
NEVER USE THE DISTRESS CALL WHEN
YOUR SHIP IS NOT IN AN EMERGENCY. A
DISTRESS CALL CAN BE USED ONLY WHEN
IMMEDIATE HELP IS NEEDED.
q Confirm no distress call is being received.
w While lifting up the switch cover, push [DISTRESS] for 5
sec. to transmit the distress call.
• An emergency channel (Ch 70) is automatically selected and the
distress call is transmitted.
• When no GPS is connected, input your position and UTC time, if
possible.
e After transmitting the call, the transceiver waits for an ac-
knowledgment call on Ch 70.
•The distress call is automatically transmitted every 3.5 to 4.5
minutes.
r After 5 sec., the transceiver is set to Channel 16 automat-
ically.
BUSY-25W---INT---CALL
LOCAL--DUP
SCRAM--TAG
NORMAL-SCAN
Wait ACK
-34"34.506N
<CLR˘
Cancel ACK---CALLING
Distress Call
TX Complete
Now Wating for ACK
<CLR˘Cancel ACK>
Distress Call
Push for 5 sec.
