DSC OPERATION
r Push [ENT] to transmit the polling request call.
t After the polling request call has been transmitted, the fol-
lowing indication is displayed
y Push [CLR] to exit the condition.
• Even if [CLR] hasn’t been pushed, the display automatically re-
turns to the original indication after 5 sec. of inactivity.
DD
Transmitting Polling reply call
Transmit a polling reply call when a polling request call is re-
ceived.
q When a polling request call is received, the following indi-
cation is displayed.
w Push [ENT] to reply to the polling request call; push [CLR]
to ignore the polling request call.
BUSY-25W---INT---CALL
LOCAL--DUP
SCRAM--TAG
ReceivedCAN
POLL REQ
<Chuck3
<CLR˘Exit>
<ENT˘Reply>COMMERCIAL
˘
Polling Request
TX Complete
--DSC Menu--
<CLR˘Exit>
Now Waiting for ACK
Polling Request Ready
˘<CLR˘Exit / ENT˘OK>
--DSC Menu--
6
