![Icom IC-M602 [38/78] Dsc operation](/views2/1074668/page38/bg26.png)
32
6
DSC OPERATION
r Set the individual ID and ID name.
•Edit the 9-digits of the appropriate distress ID directly with the
keypad.
• Push keypad several times to edit the character.
• Rotate [CHANNEL] to move the cursor backward or forward.
• Push [CE] to clear the ID and name.
• Push [CLR] to cancel and exit the condition to DSC set up menu.
t Push [ENT] to program and exit the condition to DSC set
up menu.
DD
Deleting address ID
q Push [MENU] to enter the DSC menu.
w Rotate [CHANNEL] to select “Set up,” push [ENT].
e Rotate [CHANNEL] to select “DEL: INDV ID,” push
[ENT].
•When no address ID is programmed, the transceiver exits the
condition automatically.
r Rotate [CHANNEL] to select the desired ID name for delet-
ing.
t Push [ENT] to delete the address ID and exit the condition.
Select ID
<CLR˘Exit / ENT˘OK>
˘Turtle
˘Margaret
--DSC Menu--
˘
˘Ricky
˘John
Set up
˘MMSI Check
˘Add:INDV ID
˘DEL:INDV ID
--DSC Menu--
˘Offset time
˘DEL:Group ID
˘Add:Group ID
Add:Individual ID
Input 9 digits
Input name
--DSC Menu--
˘
__________________
˘
ä________________
