![Icom IC-M602 [44/78] I received messages](/views2/1074668/page44/bg2c.png)
38
6
DSC OPERATION
■ Received messages
The transceiver automatically stores up to 20 distress mes-
sages and 20 other messages. The messages can be used
as an assistance to the logbook.
q Push [MENU] to select the DSC menu.
w Rotate [CHANNEL] to select “Received Calls,” push
[ENT].
DD
Distress message
q Rotate [CHANNEL] to select “Distress,” push [ENT].
w Rotate [CHANNEL] to scroll to the desired message, push
[ENT].
•When some messages are blinking, the messages have not
been read yet.
e Rotate [CHANNEL] to scroll the message.
r Push [CLR] to exit the condition or push [CE] to clear the
displayed message and returns to DSC menu.
Distress
<Chuck3
LAT: 23"45.234N
--DSC Menu--
LON:123"45.456W
MOB
<CLR˘Exit / CE˘Del>
Distress
--DSC Menu--
UTC: 8:00
LAT: 23"45.234N
LON:123"45.456W
MOB
<CLR˘Exit / CE˘Del>
--DSC Menu--
<CLR˘Exit / ENT˘OK>
Select Item
˘16:00 Ricky
˘14:56 Chuck3
˘12:34 Smith
--DSC Menu--
<CLR˘Exit / ENT˘OK>
Select Message
˘Distress
˘Other
Select item
˘Exit
˘Position Request
˘Received Calls
--DSC Menu--
˘Set up
˘Distress Setting
˘Polling Request
