SPECIFICATION AND OPTIONS
■ Options
• MB-75 FLUSH MOUNT (p. 51)
For mounting the transceiver to a panel.
• UT-112 VOICE SCRAMBLER UNIT (pgs. 13, 47)
Ensures private communications. 32 codes are available. Not
available in some countries.
• HM-127 REMOTE-CONTROL MICROPHONE (p. 58)
External microphone-type controller. Provides optional inter-
com operation. 6 m (20 feet) microphone cable and mount-
ing base included. Black and white colors are available.
• HM-136 SMART-SPEAKER-MICROPHONE (p. 7)
Same as supplied. Black and white colors are available.
• OPC-999 MICROPHONE EXTENSION CABLE
6 m (20 feet) microphone extension cable for optional
HM-127. Up to 2 OPC-999 can be connected. (18 m; 60 feet
maximum)
