15 Technical data
Installer reference guide
114
EVLQ05+08CAV3 + EHYHBH05AA + EHYHBH/X08AA +
EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1A – 2016.02
15.7 Technical specifications
15.7.1 Technical specifications: Outdoor unit
Nominal capacity and nominal input
Heating only type Reversible type
Outdoor units EVLQ05CAV3 EVLQ08CAV3 EVLQ08CAV3
Indoor units EHYHBH05 EHYHBH08 EHYHBX08
Condition 1
(a)
Heating capacity Minimum 1.80kW
Nominal 4.40kW 7.40kW
Maximum 5.12kW 10.02kW
Cooling capacity Minimum — 2.50kW
Nominal — 6.86kW
Maximum —
Heating PI Nominal 0.87kW 1.66kW
Cooling PI Nominal — 2.01kW
COP Nominal 5.04 4.45
EER Nominal — 3.42
Condition 2
(b)
Heating capacity Minimum 1.80kW
Nominal 4.03kW 6.89kW
Maximum 4.90kW 9.53kW
Cooling capacity Minimum — 2.50kW
Nominal — 5.36kW
Maximum —
Heating PI Nominal 1.13kW 2.01kW
Cooling PI Nominal — 2.34kW
COP Nominal 3.58 3.42
EER Nominal — 2.29
(a) In heating: Ambient temperature DB/WB 7°C/6°C – leaving water condenser 35°C (DT=5°C). In cooling: Ambient temperature 35°C – leaving
water evaporator 18°C (DT=5°C)
(b) In heating: Ambient temperature DB/WB 7°C/6°C – leaving water condenser 45°C (DT=5°C). In cooling: Ambient temperature 35°C – leaving
water evaporator 7°C (DT=5°C)
Technical specifications
Heating only type Reversible type
Outdoor units EVLQ05CAV3 EVLQ08CAV3 EVLQ08CAV3
Indoor units EHYHBH05 EHYHBH08 EHYHBX08
Casing
Colour Ivory white
Material Polyester painted galvanised steel
Dimensions
Packing (H×W×D) 797×990×390mm
Unit (H×W×D) 735×832×307mm
Weight
Machine weight 54kg 56kg
Gross weight 57kg 59kg
Packing
Material EPS, carton
Weight 3kg
Heat exchanger
