15 Technical data
Installer reference guide
118
EVLQ05+08CAV3 + EHYHBH05AA + EHYHBH/X08AA +
EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1A – 2016.02
15.7.2 Technical specifications: Indoor unit
Technical specifications
Heating only type Reversible
type
Indoor units EHYHBH05 EHYHBH08 EHYHBX08
Connected to outdoor unit EVLQ05CAV3 EVLQ08CAV3 EVLQ08CAV3
Nominal input (indoor unit only) 75W
Casing
Colour White
Material Pre-coated sheetmetal
Dimensions
Packing (H×W×D) 1240×528×262
Unit (H
(1)
×W×D) 902×450×164
Weight of machine (net) 30kg 31.2kg
Weight of machine (packed) 33kg 34.4kg —
Packing materials
Material Carton/EPS/PP (straps)
Weight 3kg
PED
Category of unit Art. 3.3(*) CategoryI
Most critical part — Plate heat exchanger
Ps*V — 51bar
Ps*DN —
Main components
Pump Type DC motor
Nr. of speed Inverter controlled
Nominal ESP unit Heating
(2)
51.8kPa 19.2kPa
Heating
(3)
55.7kPa 26.0kPa
Cooling
(7)
— 44.8kPa
Cooling
(8)
— 26.5kPa
Power input 45W
Water side heat exchanger Type Brazed plated
Quantity 1
Water volume 0.9l 1.3l
Minimum water flow rate 5.0l/min
Nominal water flow rate Heating
(2)
12.6l/min 21.2l/min
Heating
(3)
11.5l/min 19.8l/min
Cooling
(7)
— 15.4l/min
Cooling
(8)
— 19.7l/min
Maximum water flow rate
(4)
Heating 23.0l/min 23.5l/min
Insulation material Elastomeric foam
Expansion vessel Volume 10l
Maximum water pressure 3bar
Pre-pressure 1bar
Water filter Diameter perforations 1
Material Body: copper+brass
Filter element: stainless steel
Water circuit
Piping connections Ø22mm
Safety valve 3 bar
Manometer
(6)
No
Drain valve/fill valve No
Stop valves No
Air purge valve Yes
