15 Technical data
Installer reference guide
120
EVLQ05+08CAV3 + EHYHBH05AA + EHYHBH/X08AA +
EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1A – 2016.02
15.7.3 Technical specifications: Gas boiler
General
EHYKOMB33AA*
Function Heating – Domestic hot
water
Heat pump module EHYHBH05
EHYHBH/X08
Device category C13, C33, C43, C53, C63,
C83, C93
Gas
Gas consumption (G20) 0.78~3.39m
3
/h
Gas consumption (G25) 0.90~3.93m
3
/h
Gas consumption (G31) 0.30~1.29m
3
/h
Nox class 5
Central heating
Thermal load (Hi) 7.6~27.0kW
Heating power space heating (80/60) 8.2~26.6kW
Efficiency space heating (net calorific
value 80/60)
98%
Efficiency space heating (net calorific
value 40/30 (30%))
107%
Operation range 15~80°C
Pressure drop See ESP curve in the
installer reference guide.
Domestic hot water
Heating power domestic hot water 7.6~32.7kW
Efficiency domestic hot water (net
calorific value)
105%
Operation range 40~65°C
Domestic hot water flow rate (setpoint
60°C)
9l/min
Domestic hot water flow rate (setpoint
40°C)
15l/min
Casing
Colour White – RAL9010
EHYKOMB33AA*
Material Pre-coated sheet metal
Dimensions
Packing (H×W×D) 820×490×270mm
Unit (H×W×D) 710×450×240mm
Machine net weight 36kg
Packed machine weight 37kg
Packing material Carton/PP (straps)
Packing material (weight) 1kg
Main components
Water side heat exchanger Aluminium
Space heating water circuit
Space heating piping connections Ø22mm
Piping material Cu
Safety valve See indoor unit manual
Manometer Yes
Drain/fill valve No
Shut‑off valves No
Air purge valve Yes
Maximum pressure space heating
circuit
3bar
Domestic hot water circuit
Domestic hot water piping connections Ø15mm
Piping material Cu
Gas connection Ø15mm
Flue gas/combustion air connection Concentric connection
Ø60/100mm
Electrical
Power supply voltage 230V
Power supply phase 1~
Power supply frequency 50Hz
IP class IP44
Maximum electrical power consumption 55W
Electrical power consumption (standby) 2W
Gas category and supply pressure
Country Gas category Default setting After conversion to G25 After conversion to G31
Germany II2ELL3P G20 (20mbar) G25 (25mbar) G31 (28~50mbar)
Belgium
4
I2E(s)3Pc,
I3P
G20 (20mbar) G25 (25mbar) G31 (30mbar)
France II2Esi3P G20 (20mbar) G25 (25mbar) G31 (30mbar)
Italy II2H3P G20 (20mbar) — G31 (30mbar)
United Kingdom II2H3P G20 (20mbar) — G31 (30~37mbar)
Spain II2H3P G20 (20mbar) — G31 (30~37mbar)
Austria II2H3P G20 (20mbar) — G31 (30~50mbar)
Bulgaria II2H3P G20 (20mbar) — G31 (30mbar)
Czech Republic II2H3+,
II2H3P
G20 (20mbar) — G31 (37mbar)
Croatia II2H3P G20 (20mbar) — G31 (30mbar)
Hungary II2HS3P G25 (25mbar) — G31 (30mbar)
Slovakia II2H3P G20 (20mbar) — G31 (30~50mbar)
Slovenia II2H3P G20 (20mbar) — G31 (37mbar)
(4)
Any modifications to the gas valve MUST be performed by a certified representative of the manufacturer. For more
information, contact your dealer.
