13 Troubleshooting
Installer reference guide
94
EVLQ05+08CAV3 + EHYHBH05AA + EHYHBH/X08AA +
EHYKOMB33AA
Daikin Altherma hybrid heat pump
4P355634-1A – 2016.02
INFORMATION
In case of error code AH and no interruption of the
disinfection function occurred due to domestic hot water
tapping, following actions are recommended:
▪ When the Domestic hot water > Type > Reheat or
Reheat + sched. is selected, it is recommended to
program the start-up of the disinfection function at least
4 hours later than the last expected large hot water
tapping. This start-up can be set by installer settings
(disinfection function).
▪ When the Domestic hot water > Type > Scheduled only
is selected, it is recommended to program a Storage
eco 3 hours before the scheduled start-up of the
disinfection function to preheat the tank.
NOTICE
When the minimum water flow (in relation to the applicable
operation mode) is lower than described in the table below,
the unit will stop operation and the user interface will
display error 7H.
Minimum required flow during heat pump operation
05 models 7l/min
08 models Heating 8l/min
Cooling 8l/min
Minimum required flow during defrost operation
05 models 7l/min
08 models 8l/min
INFORMATION
Error AJ-03 is reset automatically from the moment there is
a normal tank heat-up.
INFORMATION
If a U6‑36 error occurs, press the gas boiler’s On/off
button.
Error codes of the outdoor unit
Error code Detailed error
code
Description
A5 00 OU: High pressure cooling/Peak
cut/ freeze protection problem.
Please contact your dealer.
E1 00 OU: PCB defect.
Power reset required.
Please contact your dealer.
E3 00 OU: Actuation of high pressure
switch (HPS).
Please contact your dealer.
E5 00 OU: Overheat of inverter
compressor motor.
Please contact your dealer.
E6 00 OU: Compressor startup defect.
Please contact your dealer.
E7 00 OU: Malfunction of outdoor
unit fan motor.
Please contact your dealer.
Error code Detailed error
code
Description
E8 00 OU: Power input overvoltage.
Please contact your dealer.
EA 00 OU: Cool/heat switchover
problem.
Please contact your dealer.
H0 00 OU: Voltage/current sensor
problem.
Please contact your dealer.
H3 00 OU: Malfunction of high
pressure switch (HPS)
Please contact your dealer.
H6 00 OU: Malfunction of position
detection sensor.
Please contact your dealer.
H8 00 OU: Malfunction of compressor
input (CT) system.
Please contact your dealer.
H9 00 OU: Malfunction of outdoor
air thermistor.
Please contact your dealer.
F3 00 OU: Malfunction of discharge
pipe temperature.
Please contact your dealer.
F6 00 OU: Abnormal high pressure
in cooling.
Please contact your dealer.
FA 00 OU: Abnormal high pressure,
actuation of HPS.
Please contact your dealer.
JA 00 OU: Malfunction of high
pressure sensor.
Please contact your dealer.
J3 00 OU: Malfunction of discharge
pipe thermistor.
Please contact your dealer.
J6 00 OU: Malfunction of heat
exchanger thermistor.
Please contact your dealer.
L3 00 OU: Electrical box temperature
rise problem.
Please contact your dealer.
L4 00 OU: Malfunction of inverter
radiating fin temperature rise.
Please contact your dealer.
L5 00 OU: Inverter instantaneous
overcurrent (DC).
Please contact your dealer.
