VM5404HA / VM5808HA User Manual
82
Configure other IP settings as needed. Default settings are indicated in
bold.
IP Address – 192.168.0.60
Subnet Mask – 255.255.255.0
Default Gateway – 192.168.0.1
Website Timeout* – N/A, 5, 10, 30, 60 minutes
Telnet Configuration – enabled
Note:
The Website Timeout setting controls how long an inactive web
connection stays logged into the VM5404HA / VM5808HA. Any
changes will take effect immediately. The default setting is 5 minutes.
To reset the system network settings, go to Settings > Maintenance >
System Setup, and then click the reset to default button.
3. Enter the values, then click Save. Changes may take a few seconds and
after refreshing the page automatically redirects you to the IP address
specified.
