ASUS RAMPAGE V EXTREME
3-17
Chapter 3
DRAM IOL (CHB D0 R1) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHB D1 R0) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHB D1 R1) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHC D0 R0) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHC D0 R1) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHC D1 R0) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHC D1 R1) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHD D0 R0) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHD D0 R1) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHD D1 R0) [Auto]
Conguration options: [Auto] [1] - [255]
DRAM IOL (CHD D1 R1) [Auto]
Conguration options: [Auto] [1] - [255]
IO control
MC Vref(CHA) [Auto]
Conguration options: [Auto] [50] - [99.911]
MC Vref(CHB) [Auto]
Conguration options: [Auto] [50] - [99.911]
MC Vref(CHC) [Auto]
Conguration options: [Auto] [50] - [99.911]
MC Vref(CHD) [Auto]
Conguration options: [Auto] [50] - [99.911]
DRAM Vref (CHA) [Auto]
Conguration options: [Auto] [60] - [99]
DRAM Vref (CHB) [Auto]
Conguration options: [Auto] [60] - [99]
DRAM Vref (CHC) [Auto]
Conguration options: [Auto] [60] - [99]
DRAM Vref (CHD) [Auto]
Conguration options: [Auto] [60] - [99]
CTL Vref (CHAB) Sign [+]
Conguration options: [+] [-]
CTL Vref (CHAB) [Auto]
Conguration options: [Auto] [0.00] - [0.20]
