Chapter 4: Software support
Chapter 4
Support DVD main menu
Click or tap an icon to display DVD/motherboard information
Click or tap an
item to install
Click to
launch InstAll
installation
wizard
Drivers menu
Clicktodisplaytheavailabledevicedriversforsystem-detecteddevices.Installthe
necessarydriverstousefortheinstalleddevices.
Utilities menu
Clicktodisplaythelistofapplicationsandothersoftwarethatthemotherboard
supports.
Manual menu
Clicktoseethelistofsupplementaryusermanuals.Clickanitemtoopenthefolder
oftheusermanual.
Video menu
ClicktoseeROGproductrelatedvideos.
Contact menu
ClicktodisplaytheASUScontactinformation.
Specials menu
ClicktoseeASUSrelatedproductinformation.
