xii
Internal I/O Connectors
2 x USB 3.0 connectors support additional 4 USB 3.0 ports
2 x USB 2.0 connectors support additional 4 USB 2.0 ports
[one connector via ROG_EXT header]
2 x SATA Express (compatible with 4 SATA 6Gb/s ports)
8 x SATA 6Gb/s connectors
1 x ROG extension (ROG_EXT) header
1 x 4-Pin CPU fan connector
1 x 4-Pin CPU optional fan connector
6 x 4-Pin Chassis fan connectors
3 x Thermal sensor connectors
1 x 24-pin EATX power connector
1 x 8-pin EATX 12V power connector
1 x 4-pin EATX 12V power connector
1 x EZ Plug connector
9 x ProbeIt Measurement Points
1 x Power-on button
1 x Reset button
1 x Safe boot button
1 x ReTry button
1 x LN2 mode jumper
1 x Slow mode switch
1 x MemOK! button
1 x M.2 Socket 3 for M Key, type 2260/2280/22110 storage devices
(supports PCIE SSDs only)
1 x KeyBot button
1 x Sonic SoundStage button
1 x BIOS Switch button
1 x Thunderbolt header (5-pin) for ASUS ThunderboldEX II series
support
1 x Front panel audio connector (AAFP)
1 x TPM connector
1 x System panel connector
Form Factor
Extended ATX Form Factor, 12-inch x 10.7-inch (30.5cm x 27.2 cm)
BIOS Features
2 x 128 Mb Flash ROM, UEFI AMI BIOS, PnP, DMI2.7, WfM2.0,
SM BIOS 2.8, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 2,
CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My
Favorites, Quick Note, Last Modied log,
F12 PrintScreen, F3 Shortcut functions, and ASUS DRAM SPD
(Serial Presence Detect) memory information.
Manageability
WfM2.0, DMI2.7, WOL by PME, PXE
(continued on the next page)
RAMPAGE V EXTREME specifications summary
__E9550_R5E_UG.indb 12 8/7/2014 2:11:12 PM
