3-22
Chapter 3: BIOS setup
Chapter 3
Tweaker’s Paradise
BCLK Amplitude [Auto]
This item allows you to adjust the magnitude of the BCLK.
Conguration options: [Auto] [Lower] [Normal] [Higher]
ICC Ringback Canceller [Disabled]
Allows you to enable the ICC Ringback Canceller.
Conguration options: [Auto] [Enabled] [Disabled]
Cross-Talk Cancellation Voltage [Disabled]
Conguration options: [Auto] [Enabled] [Disabled]
ICC Ringback Canceller [Auto]
Allows you to enable the ICC Ringback Canceller.
Gen3 Preset [Auto]
Selecting differenct presents can improve the stability of PCIE 3.0/
Conguration options: [Auto] [Preset1] [Preset] Preset3
PCIE Clock Amplitude [Auto]
Enable this item to enhance the power saving condition.
Conguration options: [Auto] [Normal] [Higher]
Do not remove the thermal module when the manual mode is selected. The thermal
conditions should be monitored.
__E9550_R5E_UG.indb 22 8/7/2014 2:11:26 PM
