Chapter 3: BIOS setup
Chapter 3
Boot from Network Devices [Legacy OpROM first]
This item allows you to select the type of network devices that you want to launch.
Conguration options: [Ignore] [Legacy OpROM rst] [UEFI driver rst]
Boot from Storage Devices [Legacy OpROM first]
This item allows you to select the type of storage devices that you want to launch.
Conguration options: [Both, Legacy OpROM rst] [Both, UEFI rst] [Legacy OpROM
rst] [UEFI driver rst] [Ignore]
Boot from PCI-E/PCI Expansion Devices [Legacy OpROM first]
This item allows you to select the type of PCIe/PCI expansion devices that you want to
launch.
Conguration options: [Legacy OpROM rst] [UEFI driver rst]
Secure Boot menu
This item allows you to congure the Windows
®
Secure Boot settings and manage its keys to
protect the system from unauthorized access and malwares during POST.
OS Type [Windows UEFI Mode]
[Windows UEFI Mode] This item allows you to select your installed
operating system. Execute the Microsoft
®
Secure
Boot check. Only select this option when booting on
Windows
®
UEFI mode or other Microsoft
®
Secure
Boot compliant OS.
[Other OS] Get the optimized function when booting on
Windows
®
non-UEFI mode. Microsoft
®
Secure Boot
only supports Windows
®
UEFI mode.
Key Management
This item allows you to manage the Secure Boot keys.
Install Default Secure Boot keys
This item allows you to immediately load the default Security Boot keys,
Platform key (PK), Key-exchange Key (KEK), Signature database (db), and
Revoked Signatures (dbx). When the default Secure boot keys are loaded,
the PK state will change from Unloaded mode to loaded mode.
Clear Secure Boot keys
This item appears only when you load the default Secure Boot keys. This
item allows you to clear all default Secure Boot keys.
Save Secure Boot Keys
This item allows you to save the PK (Platform Keys) to a USB storage
device.
