ASUS RAMPAGE V EXTREME
4-27
Chapter 4
Wi-Fi Engine
Wi-FiEngineallowsyoutoconnecttoawirelessnetworkandsetupyourcomputerasan
accesspointforInternetconnectionsharingamongotherWi-Fienableddevices.
TouseWi-FiEngine,clickortapthe onthetop-rightcorneroftheAISuite3main
menu,thenselectWi-Fi Engine.
Wi-FiEngineisavailableonlyinselectedmotherboardmodels.
Click or tap
to set up your
computer as
a wireless
access point
Using the Client Mode
TheClientmodeallowsyoutoconnectyoursystemtoawirelessnetwork.
Tousetheclientmode:
1. ClickortapClient ModetolaunchNetwork
Connections.
2. FromtheNetworkConnectionswindow,
selectanetworkadapter.
Click or tap
to connect
to a wireless
access point
Using Wi-Fi Engine
__E9550_R5E_UG.indb 27 8/7/2014 2:11:33 PM
