ASUS RAMPAGE V EXTREME
4-55
Chapter 4
4.11 RAMDisk
RAMDiskisadata-storagesoftwarethatreservesapartofyoursystem’smemoryand
turnsitintoahigh-speedvirtualdrivewhereyoucanstorecachelesandgameappsfor
instantaccess.TheDynamicMemoryAllocationfunctioncanreleasetheunusedmemory
ofRAMDiskbacktothesystemwhenneededandhelpsextendthelifespanofyourSSDor
HDD.
ThefollowingfoldersarenotsuitableforRAMDiskoptimization.Movingthemintothe
RAMDiskmightnegativelyaffecttheperformanceofyoursystem.
• Swap file/Page file:Theswapleisapermanentstoragespaceusedasthevirtual
memoryexpansionofthesystemmemory.MovingtheswapleintotheRAMDisk
simplydefeatsthepurposeofhavingitandmaydecreaseyoursystem’sperformance.
• Startup folders:SinceRAMDiskloadsduringbootuptogetherwiththecontentsof
theJunctionfolders,changingthelocationofthestartupfoldersmaycausesystem
erroranddisableloadingyourRAMDisk.
TolaunchRAMDisk,click .
Creating/Deleting a RAMDisk drive
YourRAMDiskdriveallowsyoutoplaceyourfavoriteapplicationsandlesintoRAMsoyou
canutilizeyourRAMspeedforbetterread/writeperformance.Thelesthatarestoredinside
theRAMDiskareautomaticallybackedupeverytimeyourPCisturnedoff.
Thestartuptimemaytakeawhile,dependingonthesizeofyourRAMDiskdrive.
To create RAMDisk drives:
Click or tap to create
RAMDisk drives
Click or tap the drop-
down arrow to choose
a drive name for your
RAMDisk
Tick to enable Dynamic
Memory Allocation function
Click or tap to finish
creating the RAMDisk
drive
Move the slider to the
right to set the size
allocation
