Asus rog rampage v extreme [165/230] Chapter 4
![Asus rog rampage v extreme [165/230] Chapter 4](/views2/1161002/page165/bga5.png)
ASUS RAMPAGE V EXTREME
4-15
Chapter 4
• WhenyouenableConguredMaxCPUPowerfortheadvancedenergysaving
condition,theCPUfrequencymaydisplay800MHzintheWindows
®
OSinformation
ofyourcomputer.However,thetrueCPUfrequencyvariesdependingonthe
wattagethatyoumanuallyset.YoucanadjusttheCPUwattagefromthelowest
basedonyourpreferreddefaultvalue.
• ConguredMaxCPUPowermaydecreasethetotalpowerdeliverytotheCPUand
affectstheCPUperformanceundersystemheavyload.Torestoreyoursystemtoits
defaultsettings,rebootyourcomputer.
Power Saving
Click or tap
to apply the
adjustments
Click or tap to undo the adjustments
Click or tap to apply the
default settings
Tick to select Voltage Decrement setting
Move the
sliders to
adjust monitor
and system
sleep time
Move the sliders to adjust Configured
Max CPU Power settings
Click or tap to select a fan profile
Tick to enable Away Mode
__E9550_R5E_UG.indb 15 8/7/2014 2:11:32 PM
