Asus rog rampage v extreme [17/230] Installation tools and components
![Asus rog rampage v extreme [17/230] Installation tools and components](/views2/1161002/page17/bg11.png)
xvii
Installation tools and components
1 set of screws Philips (cross) screwdriver
PC chassis Power supply unit
Intel LGA 2011-3 CPU Intel LGA 2011-3 compatible CPU Fan
DDR4 DIMM SATA hard disk drive
Graphics card SATA optical disc drive (optional)
The tools and components in the table above are not included in the motherboard package.
__E9550_R5E_UG.indb 17 8/7/2014 2:11:12 PM
