ASUS RAMPAGE V EXTREME
2-7
Chapter 2
Replacing the LGA2011-v3 CPU pad (X-Socket 2)
The X-Socket 2 is a unique ROG feature that allows the user to use their LN2 pot on the
LGA 2011-v3 motherboard.
__E9550_R5E_UG.indb 7 8/7/2014 2:11:21 PM
