2-16
Chapter 2: Basic Installation
Chapter 2
• WestronglyrecommendthatyouconnectUSB3.0devicestoUSB3.0portsforfaster
andbetterperformanceforyourUSB3.0devices.
• WhenusingtheexternalSATAport,ensuretouseacompatibleconnector.
Port
Headset
2-channel
4-channel 6-channel 8-channel
LightBlue Line In Line In Line In Side Speaker Out
Lime Line Out Front Speaker Out Front Speaker Out Front Speaker Out
Pink MicIn MicIn MicIn MicIn
Orange – – Center/Subwoofer Center/Subwoofer
Black – Rear Speaker Out Rear Speaker Out Rear Speaker Out
*** Audio 2, 4, 6 or 8-channel configuration
* LAN ports LED indications
ACT/LINK
LED
SPEED
LED
LAN port
Activity Link LED Speed LED
Status Description Status Description
Off
No link Off 10Mbpsconnection
Orange
Linked Orange 100Mbpsconnection
Orange(Blinking)
Data activity Green 1 Gbps connection
Orange(Blinking
then steady)
Ready to wake up
from S5 mode
TheBluetoothwordmarkandlogosareownedbyBluetoothSIG,Inc.andanyuseofsuch
mark by ASUSTeK Computer Inc. is under license. Other trademarks and trade names are
those of their respective owners.
** Bluetooth and Wi-Fi module LED indications
Wi-Fi 802.11 a/b/g/n/ac,
Bluetooth v4.0
Wi-Fi LED Bluetooth LED
Status Description Status Description
Off No link Off No link
Green Linked Blue Linked
Blinking Data activity
Wi-Fi LED
YoucandisabletheLANcontrollersinBIOS.Duetohardwaredesign,theLAN1port’s
LEDs may continue to blink even when disabled.
