Asus rog rampage v extreme [15/230] Oc panel specifications summary
![Asus rog rampage v extreme [15/230] Oc panel specifications summary](/views2/1161002/page15/bgf.png)
xv
Display
2.6-inch LCM
Features
Pure hardware-based overclocking support
Boot debug POST code
Intuitive tuning in two OC modes
- EXTREME Mode for subzero OC benching*
- NORMAL Mode for in-chassis usage**
Seamless integration with CPU Level Up at one-click OC button
Real-time control and display CPU fan speed, temperature, BCLK
and RATIO
Adjustable system voltages, frequencies on-the-y
Stylish design with 90 plus-degree-tilt movable faceplate
(EXTREME Mode)
FanSpeed Control button
- Standard/Silent/Turbo mode
Four (4) additional 4-pin fan headers
LCM backlight on/off
ROG exclusive features
- VGA Hotwire
- Subzero Sense
- Slow Mode
- Pause Switch
- VGA SMB header
- ProbeIt
* EXTREME MODE capabilities, including V1, V2, DRAM and other
voltage definitions, vary by chipset. Please refer to your motherboard
manual for details.
** One 5.25-inch drive bay is required for NORMAL Mode installation
I/O Ports
POWER : 1 x SATA power connector
ROG_EXT port : 1 x 18-1 pin data connection port
FAN : 4 x 4-pin extra Fan connectors
Power
Voltage: +12V, +5V, +5VSB
Power consumption: 5A
Installation
Requirements
1 x 5.25-inch drive bay required for NORMAL Mode installation
1 x SATA power cable from system power supply
Compatibility
RAMPAGE V EXTREME and other motherboards with ROG_EXT
port
* Visit the ASUS website at www.asus.com for the latest motherboard
support/compatibility lists.
** Install the latest utility/firmware (ROG Connect Plus) for better
compatibility.
OC Panel specifications summary
__E9550_R5E_UG.indb 15 8/7/2014 2:11:12 PM
