Chapter 4: Software support
Chapter 4
Afteryouclosethepop-window,SonicSenseAmpentersspeakercongurationand
displaystheadjustedheadphoneimpedance.
Click or tap to manually
adjust the amplify level
Displays the impedance of
your headphone
__E9550_R5E_UG.indb 44 8/7/2014 2:11:36 PM
