2-24
Chapter 2: Basic Installation
Chapter 2
2.5 Starting up for the first time
1. After making all the connections, replace the system case cover.
2. Ensure that all switches are off.
3. Connect the power cord to the power connector at the back of the system chassis.
4. Connect the power cord to a power outlet that is equipped with a surge protector.
5. Turnonthedevicesinthefollowingorder:
a. Monitor
b. ExternalSCSIdevices(startingwiththelastdeviceonthechain)
c. System power
6. After applying power, the system power LED on the system front panel case lights
up. For systems with ATX power supplies, the system LED lights up when you press
the ATX power button. If your monitor complies with the green standards or if it has a
power standby feature, the monitor LED may light up or change from orange to green
after the system LED turns on.
The system then runs the power-on self tests (POST). While the tests are running, the
BIOSbeeps(refertotheBIOSbeepcodestable)oradditionalmessagesmayappear
on the screen. If you do not see anything within 30 seconds from the time you turned
on the power, the system may have failed a power-on test. Check the jumper settings
and connections or call your retailer for assistance.
BIOS Beep Description
One short beep
VGAdetected
Quick boot set to disabled
No keyboard detected
One continuous beep followed by two
short beeps then a pause (repeated)
No memory detected
One continuous beep followed by three
short beeps
NoVGAdetected
One continuous beep followed by four
short beeps
Hardware component failure
7. Holddownthe<Delete>keyduringpowerontoentertheBIOSSetup.Followthe
instructions in Chapter 3.
2.6 Turning off the computer
While the system is ON, press the power button for less than four seconds to put the system
tosleepmodeorsoft-offmode,dependingontheBIOSsetting.Pressthepowerswitchfor
morethanfoursecondstoletthesystementerthesoft-offmoderegardlessoftheBIOS
setting.
