ASUS RAMPAGE V EXTREME
4-31
Chapter 4
Tolog-inusingyoursmartdevice:
1. LaunchWi-FiGO!&NFC
Remoteonyousmartdevice.
2. TapASUSAccount(A),key
inyourASUSAccountand
password,thenclickortap
Login(C).
• PCswiththesameASUSaccountloggedinwillshowupinthedevicelist.
• Thepublic-to-privatenetworkfunctionsfortheiOSsystemwillbeavailablefrom
Wi-FiGO!&NFCRemoteV2.00.00orlaterversions.
Use your smart device to scan QR
Codes for more information
Click to set a password or log in using your ASUS Account
Using Wi-Fi GO!
TolaunchWi-FiGO!,clicktheASUSHomeCloudshortcutonyourdesktop,thenselectWi-Fi
GO!fromtheminibar.
LaunchWi-FiGO!&NFCRemoteonyoursmartdevicetousetheWi-FiGO!&NFC
remotecontrolfunctions.Formoredetails,refertosectionWi-FiGO!&NFCRemoteofthis
usermanualformoredetails.
Wi-Fi GO! menu
ToprotectyourWi-Fiutilityfromunauthorizedremoteaccess,click thenseta
password.
