ASUS RAMPAGE V EXTREME
4-45
Chapter 4
Sonic SoundStage
SonicSoundStageisahardwarebasedsoundsolutionforvirtualSoundStagethatoffers
fourpresetgamingproles:FPS,Racing,FightingandSports.
• ThisfeatureisonlyavailableforfrontpanelHeadphoneoutput.
• YoucanenablethisfeaturebyenablingthededicatedSoundStagebuttononyour
motherboard.RefertotheOnboard buttonssectiononthisuserguideformore
information.
Click or tap any
of the four preset
gaming profiles
Use the slider to
manually adjust the
setting of an item
Crossing
Movetheslidertoadjusttheamountofcrosschannelmixing.
Revert
Movetheslidertorevertthemainaudiosource.
Space
Movetheslidertoadjustandvirtualizethespacesound.
Crossing gain
ThisitemonlyworkswhenCrossingandRevertisenabled.Movethesliderto
adjustthehardnessofthewall.
__E9550_R5E_UG.indb 45 8/7/2014 2:11:36 PM
