CPU Fan Min. Duty Cycle (%) [20]

Use the <+> and <-> keys to adjust the minimum CPU fan duty cycle. The values

range from 40% to 100%. When the CPU temperature is under its CPU lower

temperature setting, the CPU fan will operate at the minimum duty cycle.

Chassis Fan 1 A/B Q-Fan Control; Chassis Fan 2 A/B Q-Fan Control; Chassis

Fan 3 A/B Q-Fan Control [DC Mode]

[Disabled] Disables the Chassis Q-Fan control feature.

[DC mode] Enable the chassis Q-Fan control in DC mode for 3-pin chassis fan.

[PWM mode] Enable the chassis Q-Fan control in PWM mode for 4-pin chassis fan.

Chassis Fan 1 A/B Q-Fan Source; Chassis Fan 2 A/B Q-Fan Source; Chassis Fan

3 A/B Q-Fan Source [CPU]

The assignment fan will be controlled according to the selected temperature source.

Conguration options: [CPU] [MB] [VRM] [MB] [T_SENSOR1] [EXT_SENSOR1] [EXT_

SENSOR2] [EXT_SENSOR3]

For T_SENSOR1, connect a Thermistor cable to the T_SENSOR1 header then place the

other end to a component to get the temperature.

Chassis Fan 1 A/B Fan Speed Low Limit; Chassis Fan 2 A/B Fan Speed Low

Limit; Chassis Fan 3 A/B Fan Speed Low Limit [300 RPM]

This item appears only when you enable the Chassis Q-Fan Control feature and allows

you to disable or set the chassis fan warning speed.

Conguration options: [Ignore] [200 RPM] [300 RPM] [400 RPM] [500 RPM] [600 RPM]

The following items appear only when you set the Chassis1/Chassis2/Chassis3 Q-Fan

Control feature to [Enabled].

Chassis Fan 1 A/B Profile; Chassis Fan 2 A/B Profile; Chassis Fan 3 A/B Profile

[Standard]

This item allows you to set the appropriate performance level of the chassis fan.

[Standard] Sets to [Standard] to make the chassis fan automatically adjust

depending on the chassis temperature.

[Silent] Sets to [Silent] to minimize the fan speed for quiet chassis fan

operation.

[Turbo] Sets to [Turbo] to achieve maximum chassis fan speed.

[Manual] Sets to [Manual] to assign detailed fan speed control parameters.

The following items appear only when you set Chassis Fan 1 A/B Prole, Chassis Fan 2

A/B Prole, Chassis Fan 3 A/B Prole to [Manual].

Chassis Fan 1/2/3 Upper Temperature [70]

Use the <+> or <-> keys to adjust the upper limit of the CPU temperature. The values

range from 20°C to 75°C.
