ASUS RAMPAGE V EXTREME
3-19
Chapter 3
MISC
DRAM Eventual Voltage (CHA/CHB/CHC/CHD) [Auto]
Use <+> or <-> to adjust the eventual voltages of the DIMM slots. The values range
from 0.8 V to 1.9 V with a 0.10 increment.
DQ/ DQS/ CMD/ CTL Sense Amp Sign [+]
Conguration options: [+] [-]
DQ/ DQS/ CMD/ CTL Sense Amp [Auto]
Conguration options: [Auto] [0] – [127]
DRAM CLK Period [Auto]
This item allows you to set a DRAM clock period.
Conguration options: [Auto] [1] – [19]
Memory optimize Control [Auto]
This item allows you to optimize the memory control.
Conguration options: [Auto] [Enabled] [Disabled]
Enhanced Training (CHA)/ (CHB)/ (CHC)/ (CHD) [Auto]
Conguration options: [Auto] [Enabled] [Disabled]
MemTest [Disabled]
Conguration options: [Auto] [Enabled] [Disabled]
Attempt Fast Boot [Auto]
Conguration options: [Auto] [Enabled] [Disabled]
DRAM Training [Auto]
Conguration options: [Auto] [Enabled] [Disabled]
MemTest on Fast Boot [Disabled]
Conguration options: [Auto] [Enabled] [Disabled]
__E9550_R5E_UG.indb 19 8/7/2014 2:11:26 PM
