DGS-3312SR Layer 3 Gigabit Switch

111

Priority-2 -> <Class-1>

Priority-3 -> <Class-3>

Priority-4 -> <Class-4>

Priority-5 -> <Class-5>

Priority-6 -> <Class-6>

Priority-7 -> <Class-7>

DGS-3312SR:4#

config 802.1p default_priority

Purpose Used to specify default priority settings on the switch. Untagged

packets that are received by the switch will be assigned a priority

tag in its priority field using this command.

Syntax

config 802.1p default_priority [<portlist> | all] <priority 0-7>

Description

The config 802.1p default_priority command allows you to

specify the 802.1p priority value an untagged, incoming packet will

be assigned before being forwarded to its destination.

Parameters

<portlist> − Specifies a range of ports to be configured. The port

list is specified by listing the lowest switch number and the

beginning port number on that switch, separated by a colon. Then

the highest switch number, and the highest port number of the

range (also separated by a colon) are specified. The beginning

and end of the port list range are separated by a dash. For

example, 1:3 specifies switch number 1, port 3. 2:4 specifies

switch number 2, port 4. 1:3-2:4 specifies all of the ports between

switch 1, port 3 and switch 2, port 4 − in numerical order.

all − Specifies that the config 802.1p default_priority command

will be applied to all ports on the switch.

<priority 0-7> − Specifies the 802.1p priority tag that an untagged,

incoming packet will be given before being forwarded to its

destination.

Restrictions Only administrator-level users can issue this command.

Example usage:

To configure 802.1p default priority on the switch:

DGS-3312SR:4#config 802.1p default_priority all 5

Command: config 802.1p default_priority all 5

Success.

DGS-3312SR:4#
