DGS-3312SR Layer 3 Gigabit Switch

204

show 802.1x auth_state

Parameters

ports <portlist> − Specifies a range of ports. The port list is

specified by listing the lowest switch number and the beginning

port number on that switch, separated by a colon. Then highest

switch number, and the highest port number of the range (also

separated by a colon) are specified. The beginning and end of

the port list range are separated by a dash. For example, 3

would specify port 3. 4 specifies port 4. 3-4 specifies all of the

ports between port 3 and port 4 − in numerical order.

The following details what is displayed:

Port number − Shows the physical port number on the switch.

Auth PAE State: Initialize / Disconnected / Connecting /

Authenticating / Authenticated / Held / ForceAuth / ForceUnauth

− Shows the current state of the Authenticator PAE.

Backend State: Request / Response / Fail / Idle / Initialize /

Success / Timeout − Shows the current state of the Backend

Authenticator.

Port Status: Authorized / Unauthorized − Shows the result of the

authentication process. Authorized means that the user was

authenticated, and can access the network. Unauthorized

means that the user was not authenticated, and cannot access

the network.

Restrictions Only administrator-level users can issue this command.

Example usage:

To display the 802.1x auth state:

DGS-3312SR:4#show 802.1x auth_state 1:1-1:12

Command: show 802.1x auth_state 1:1-1:12

Port Auth PAE State Backend State Port Status

------ ----------------------- --------------------- -----------------

1:1 ForceAuth Success Authorized

1:2 ForceAuth Success Authorized

1:3 ForceAuth Success Authorized

1:4 ForceAuth Success Authorized

1:5 ForceAuth Success Authorized

1:6 ForceAuth Success Authorized

1:7 ForceAuth Success Authorized

1:8 ForceAuth Success Authorized

1:9 ForceAuth Success Authorized

1:10 ForceAuth Success Authorized

1:11 ForceAuth Success Authorized
