DGS-3312SR Layer 3 Gigabit Switch

220

Command: delete access_profile profile_id 1

Success.

DGS-3312SR:4#

config access_profile

Purpose Used to configure an access profile on the switch and to define

specific values that will be used to by the switch to determine if a given

packet should be forwarded or filtered. Masks entered using the

create access_profile command will be combined, using a logical

AND operation, with the values the switch finds in the specified frame

header fields. Specific values for the rules are entered using the

config access_profile command, below.

Syntax

<value 1-255>[ add access_id <value 1-255> [ethernet {vlan

<vlan_name 32> | source_mac <macaddr> | destination_mac

<macaddr> | 802.1p <value 0-7> | ethernet_type <hex 0x0-0xffff>

[permit {priority <value 0-7> {replace_priority }} | deny ] | ip {vlan

<vlan_name 32> | source_ip <ipaddr> | destination_ip <ipaddr> |

dscp <value 0-63> | [icmp {type <value 0-255> code <value 0-

255>} | igmp {type <value 0-255>} | tcp {src_port <value 0-65535>

| dst_port <value 0-65535> | flag_mask [all | {urg | ack | psh | rst |

syn | fin}]} | udp {src_port <value 0-65535> | dst_port <value 0-

65535>} | protocol_id <value 0 - 255> {user_define <hex 0x0-

0xffffffff>}]} [permit {priority <value 0-7> {replace_priority }} |

deny ] | packet_content {offset_0-15 <hex 0x0-0xffffffff> <hex 0x0-

0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_16-31

<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex

0x0-0xffffffff> | offset_32-47 <hex 0x0-0xffffffff> <hex 0x0-

0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> | offset_48-63

<hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff> <hex

0x0-0xffffffff> | offset_64-79 <hex 0x0-0xffffffff> <hex 0x0-

0xffffffff> <hex 0x0-0xffffffff> <hex 0x0-0xffffffff>}] [permit

{priority <value 0-7> {replace_priority} | deny] | delete access_id

<value 1-255>]

Description

The config access_profile command is used to configure an access

profile on the switch and to enter specific values that will be combined,

using a logical AND operation, with masks entered with the create

access_profile command, above.
