DGS-3312SR Layer 3 Gigabit Switch

SWITCH UTILITY COMMANDS

The switch utility commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the

following table.

Command Parameters

download [ firmware <ipaddr> <path_filename 64> {unit [all | master | <unitid

1-13>]} | configuration <ipaddr> <path_filename 64> {increment} ]

upload [ configuration | log ] <ipaddr> <path_filename 64> ]

ping <ipaddr> {times <value 1-255>} {timeout <sec 1-99>}

traceroute <ipaddr> {ttl <value 1-60> | port <value 30000-64900> | timeout

<sec 1-65535> | probe <value <1-9>

Each command is listed, in detail, in the following sections.

download

Purpose Used to download and install new firmware or a switch

configuration file from a TFTP server.

Syntax

download [ firmware <ipaddr> <path_filename 64> {unit [all |

master | <unitid 1-13>]} | configuration <ipaddr>

<path_filename 64> {increment} ]

Description This command is used to download a new firmware or a switch

configuration file from a TFTP server.

Parameters

firmware − Download and install new firmware on the switch from a

TFTP server.

configuration - Download a switch configuration file from a TFTP

server.

unit [all | <unitid 1-13>] − all specifies all units (switches), <unitid>

is the unit ID of the switch that will receive the download.

master

−

specifies the master switch in a switch stack.

<ipaddr> − The IP address of the TFTP server.

<path_filename> − The DOS path and filename of the firmware or

switch configuration file on a TFTP server. For example,

C:\3226S.had.

increment − Allows the download of a partial switch configuration

file. This allows a file to be downloaded that will change only the

switch parameters explicitly stated in the configuration file. All other

switch parameters will remain unchanged.

Restrictions The TFTP server must be on the same IP subnet as the switch.

Only administrator-level users can issue this command.
