DGS-3312SR Layer 3 Gigabit Switch
85
Example usage:
To create a spanning tree instance 2:
DGS-3312SR:4#create stp instance_id 2
Command: create stp instance_id 2
Success.
DGS-3312SR:4#
config stp instance_id
Purpose Used to add or delete an STP instance ID.
Syntax
config stp instance_id <value 1-15> [add_vlan | remove_vlan]
<vidlist>
Description This command is used to map VIDs (VLAN IDs) to previously
configured STP instances on the Switch by creating an
instance_id. A STP instance may have multiple members with the
same MSTP configuration. There is no limit to the number of STP
regions in a network but each region only supports a maximum of
16 spanning tree instances (one unchangeable default entry).
VIDs can belong to only one spanning tree instance at a time.
Note that switches in the same spanning tree region having the
same STP instance_id must be mapped identically, and have the
same configuration revision_level number and the same name.
Parameters <value 1-15> - Enter a number between 1 and 15 to define the
instance_id. The Switch supports 16 STP instances with one
unchangeable default instance ID set as 0.
add_vlan – Along with the vid_range <vidlist>
parameter, this command will add VIDs to the previously
configured STP instance_id.
remove_vlan – Along with the vid_range <vidlist>
parameter, this command will remove VIDs to the previously
configured STP instance_id.
<vidlist> – Specify the VID range from configured
VLANs set on the Switch. Supported VIDs on the Switch
range from ID number 1 to 4094.
Restrictions Only administrator-level users can issue this command.
