DGS-3312SR Layer 3 Gigabit Switch

263

config vrrp ipif

critical_ip_state [enable | disable] – This parameter is used to enable

or disable the critical IP address entered above. The default is

disable.

Restrictions Only administrator-level users can issue this command.

Example usage:

To configure a VRRP entry:

DGS-3312SR:4#config vrrp ipif Trinity vrid 1 state enable priority

100 advertisement_interval 2

Command: config vrrp ipif Trinity vrid 1 state enable priority 100

advertisement_interval 2

Success.

DGS-3312SR:4#

config vrrp ipif authtype

Purpose To configure the authentication type for a VRRP entry.

Syntax

config vrrp ipif authtype <ipif_name 12> [none | simple authdata

<string 8> | ip authdata <string 16>]

Description This command is used to set the authentication type for a VRRP

entry on the switch.

Parameters <ipif_name 12> - Enter the name of a previously configured IP

interface that you wish to configure the VRRP entry for. This IP

interface must be assigned to a VLAN on the switch.

authtype – Specifies the type of authentication used. The authtype

must be consistent with all routers participating within the VRRP

group. The user may choose between:

 none – Entering this parameter indicates that VRRP protocol

exchanges will not be authenticated.

 simple authdata <string 8> - This parameter, along with an

alphanumeric string of no more than eight characters, to set

a simple password for comparing VRRP message packets

received by a router. If the two passwords are not exactly

the same, the packet will be dropped.

 ip authdata <string 16> - This parameter will require the user

to set an alphanumeric authentication string of no more than

16 characters to generate a MD5 message digest for

authentication in comparing VRRP messages received by

the router. If the two values are inconsistent, the packet will

be dropped.
